Sic Schottky dioda

SiC Schottky dioda je vrsta poluvodiča visokih performansi
uređaj, koji ima prednosti niskog napona otvaranja, visokog
brzina prebacivanja, performanse na visokim temperaturama, itd., i je
naširoko koristi u napajanje, pogon, inverter, električni
vozila i druge oblasti. SiC diode sviraju
sve važniju ulogu u oblasti energetske elektronike
za njihove odlične performanse i pouzdanost, pružanje
efikasnija i pouzdanija rješenja za razne aplikacije velike snage.

Pošaljite upit

Opis

Schottky dioda se sastoji od metala i N-tipa poluprovodnika,
nema P-tipa poluvodičkog sloja, obično radi vrlo dobro u
brzo prebacivanje aplikacija, obrnuto vrijeme oporavka je vrlo
kratak, i široko se koristi u visokofrekventnom padu niskog napona
scenarije, kao što su konverzija snage, ispravljanje strujnog kola, itd.

br.	VRRM(V)	IF(A)	IFSM(A)	VF(V) tip.	IR(μA)tip.	Paket
WSRSIC006065NPC	650	6	50	1.38	1	TO{0}}L
WSRSIC008065NPC	650	8	65	1.38	1.2	TO{0}}L
WSRSIC010065NPC	650	10	75	1.38	1.5	TO{0}}L
WSRSIC015065NPC	650	15	95	1.38	5	TO{0}}L
WSRSIC004065NPD	650	4	30	1.38	0.8	DFN5*6
WSRSIC006065NPD	650	6	40	1.38	1	DFN5*6
WSRSIC008065NPD	650	8	45	1.38	1.2	DFN5*6
WSRSIC006065NPE	650	6	40	1.38	1	DFN8*8-4L
WSRSIC004065NPF	650	4	30	1.38	0.8	TO-220F{1}}L
WSRSIC006065NPF	650	6	40	1.38	1	TO-220F{1}}L
WSRSIC008065NPF	650	8	50	1.38	1.2	TO-220F{1}}L
WSRSIC010065NPF	650	10	70	1.38	1.5	TO-220F{1}}L
WSRSIC006065NNI	650	6	40	1.38	1	TO-220ISO-2L
WSRSIC008065NNI	650	8	50	1.38	1.2	TO-220ISO-2L
WSRSIC010065NNI	650	10	70	1.38	1.5	TO-220ISO-2L
WSRSIC020065NNI	650	20	130	1.32	3	TO-220ISO-2L
WSRSIC005120NNI	1200	5	43	1.4	1	TO-220ISO-2L
WSRSIC010120NNI	1200	10	95	1.4	1	TO-220ISO-2L
WSRSIC010120NP4	1200	10	95	1.4	5	TO{0}}L
WSRSIC020120NP4	1200	20	160	1.4	10	TO{0}}L
WSRSIC040120NP4	1200	40	325	1.4	15	TO{0}}L
WSRSIC020065NP4	650	20	170	1.32	3	TO{0}}L
WSRSIC020065NP8	650	20(10*2)	140(70*2)	1.38	1.5	TO{0}}L
WSRSIC020120NP8	1200	20(10*2)	180(90*2)	1.4	5	TO{0}}L
WSRSIC030120NP8	1200	30(15*2)	270(135*2)	1.43	8	TO{0}}L
WSRSIC040120NP8	1200	40(20*2)	320(160*2)	1.4	10	TO{0}}L
WSRSIC004065NPO	650	4	30	1.38	0.8	TO{0}}L
WSRSIC006065NPO	650	6	40	1.38	1	TO{0}}L
WSRSIC008065NPO	650	8	50	1.38	1.2	TO{0}}L
WSRSIC002120NPO	1200	2	18	1.36	1	TO{0}}L
WSRSIC004120NPO	1200	4	30	1.36	1.5	TO{0}}L
WSRSIC005120NPO	1200	5	43	1.38	2	TO{0}}L
WSRSIC010065NPM	650	10	80	1.38	1.5	TO{0}}L
WSRSIC020065NPM	650	20	130	1.32	2	TO{0}}L
WSRSIC010120NPM	1200	10	95	1.4	5	TO{0}}L
WSRSIC020065NPL	650	20	130	1.32	3	TO-3PF-3L
WSRSIC010065NNI-AT	650	10	84	1.38	1	NA -220ISO-2L (AUTO)
WSRSIC020120NP{1}}AT	1200	20	180	1.4	3	DO{0}}L(AUTO)
WSRSIC020065NP{1}}AT	650	20	180	1.32	1	DO{0}}L(AUTO)
WSRSIC020065NP{1}}AT	650	20(10*2)	150(75*2)	1.38	1	DO{0}}L(AUTO)
WSRSIC020120NP{1}}AT	1200	20(10*2)	190(95*2)	1.4	3	DO{0}}L(AUTO)
WSRSIC030120NP{1}}AT	1200	30(15*2)	280(140*2)	1.43	3	DO{0}}L(AUTO)
WSRSIC040120NP{1}}AT	1200	40(20*2)	340(170*2)	1.4	3	DO{0}}L(AUTO)
WSRSIC010065NPO	650	10	70	1.38	1.5	TO{0}}L
WSRSIC020065NPC	650	20	152	1.38	6	TO{0}}L
WSRSIC008065NPE	650	8	45	1.38	1.2	DFN8*8-4L
WSRSIC060120NP4	1200	60	340	1.4	25	TO{0}}L
WSRSIC030065NPS	650	30	220	1.38	2	TO{0}}L
WSRSIC040065NPS	650	40	290	1.38	4	TO{0}}L
WSRSIC010120NPO	1200	10	95	1.4	5	TO{0}}L
WSRSIC010120NPCC	1200	10	95	1.4	10	SMC
WSRSIC030065NPC	650	30	220	1.38	2	TO{0}}L
WSRSIC004065NPC	650	4	30	1.38	0.8	TO{0}}L
WSRSIC030120NP4	1200	30	220	1.4	13	TO{0}}L
WSRSIC010120NP8	1200	10(5*2)	43	1.4	1	TO{0}}L
